Albert B Simon, Age 88Ellicott, MD

4699335, Oct 13, 1987

Oct 16, 1985

6/788189

James H. DeOms - Baltimore MD
Albert B. Simon - Ellicott City MD

The United States of America as represented by the Secretary of the Air
Force - Washington DC

B64C 114

2441293

An aircraft window clamping ring is used to hold an optical sensor window against an aircraft wall. The ring has a plurality of cantilevers having upper contacts that bear directly down on the window. Because of the flexibility in the vertical direction, thermal expansion is compensated for by movement of the cantilevers. Horizontal expansion of the window creates no additional stress because the upper contacts bear perpendicular to possible horizontal movement. The cantilevers can be designed to preload the window to take into account maximum thermal expansion.

4135298, Jan 23, 1979

Jun 21, 1977

5/808493

James A. Rew - Glen Burnie MD
Albert B. Simon - Ellicott City MD
Thomas M. Fahey - Laurel MD

The United States of America as represented by the Secretary of the Air
Force - Washington DC

B23P 1526

29727

A mechanically deformable heat transfer fin for installation in a hollow cavity of a large complex elongated extrusion to improve heat transfer characteristics without brazing welding or glueing. Since the required design cannot be obtained with the transfer fins as an integral part of the extrusion using presently known techniques, a separate fin insert of slightly smaller dimensions than the hollow opening of the large extrusion is installed therein. The insert includes a plurality of legs and an internal pressure cavity which can be sealed off at both ends with pressure cap fittings secured by tie rods. After installation in the extrusion, pressure is applied to the inner chamber until the legs of the insert move outward and contact the inner surface of the extrusion walls. The pressure is raised until the relatively thin walls of the insert are permanently deformed so that, when the pressure is relieved, the insert is held fixedly in place.
