Andy I Mclaughlin, Age 6526076 Garrett Ln, Orange Beach, AL 36561

5252625, Oct 12, 1993

Jun 25, 1991

7/720735

Andy I. McLaughlin - Meridian MS
Richard L. Donald - Meridian MS
Robert H. Blanpied - Meridian MS
Robert J. Butkus - Meridian MS

Atlas Roofing Corporation - Meridian MS

C08G 1818
C08G 1822
C08J 908

521125

In a method of producing a thermosetting foam, a first of two foam forming blends ("A Blend") is prepared using polymeric polymethylene polyphenylisocyanate ("PMDI"). A second of two foam forming blends ("B Blend") is prepared by mixing together a polyol; water; a tertiary amine catalyst having at least one ethyl (--CH. sub. 2 --CH. sub. 2 --) linkage between two heteroatoms, the heteroatoms being chosen from the group consisting of Nitrogen and Oxygen; and, an alkali metal organo-salt catalyst. A first blowing agent is included with one of the two foam forming blends. When the first and second foam forming blends are mixed together, the tertiary amine catalyst quickly initiates a reaction predominately of the polymeric polymethylene polyphenylisocyanate with water (as opposed to a reaction with the polyol). The quick reaction of the PMDI with water causes, prior to a gel point of the foam, both (1) the production of a second blowing agent for forming cells in the blends and for causing expansion in the liquid blends; and (2) sufficient exothermic heat to initiate boiling of the first blowing agent. Relatively large amounts of alkali metal organo-salt catalyst induce rapid vaporizing of the first blowing agent due to a high level of exothermic heat, whereby expansion of the mixed blends is substantially completed prior to the effective conversion of the mixed liquid blends to a solid.

5433050, Jul 18, 1995

Nov 10, 1993

8/149740

Allan L. Wilson - Marietta GA
Andy I. McLaughlin - Meridian MS
William E. Todd - Marietta GA
Ronald Jadlocki - La Grange GA
Russell D. Addison - La Grange GA
Timothy L. Lagod - Marietta GA

Atlas Roofing Corporation - Meridian MS

E04C 236

523021

A thermally insulative building construction panel (10) comprises a first or bottom sheet (20) of insulation material; a second or top sheet (24) of a rigid nail-anchoring material; and, a plurality of spacer members (22) sandwiched in fixed positions between the first sheet and the second sheet for defining air channels (25) between the sheets and the spacer members. The spacer members (22) are over three inches wide and are at least one-half inch thick. The spacer members (22) are comprised of a plastic foam insulation material selected from the group consisting of polyurethane modified polyisocyanurate foam, phenolic-formaldehyde foam, and polystyrene foam.

5294647, Mar 15, 1994

Feb 16, 1993

8/018304

Robert H. Blanpied - Meridian MS
Robert J. Butkus - Meridian MS
Andy I. McLaughlin - Meridian MS
Richard L. Donald - Meridian MS

Atlas Roofing Corporation - Meridian MS

C08J 914

521125

In a method of producing a thermosetting foam, a first of two foam forming blends ("A-Blend") is prepared using a multi-functional isocyanate such as polymeric polymethylene polyphenylisocyanate ("PMDI"). A second of two foam forming blends ("B-Blend") is prepared by mixing together a polyol; water; a tertiary amine catalyst having at least two hydrogen bonding sites for one molecule; and, an alkali metal organo-salt catalyst. The tertiary amine catalyst is of a type wherein both the hydrogen segment and the hydroxyl segment of water are attracted by both of the hydrogen bonding cites on the catalyst molecule essentially simultaneously. A first blowing agent is included with one of the two foam forming blends. When the first and second foam forming blends are mixed together, the tertiary amine catalyst quickly initiates a reaction predominately of the polymeric polymethylene polyphenylisocyanate with water (as opposed to a reaction with the polyol). The quick reaction of the PMDI with water causes, prior to a gel point of the foam, both (1) the production of a second blowing agent for forming cells in the blends and for causing expansion in the liquid blends; and (2) sufficient exothermic heat to initiate boiling of the first blowing agent.
