Inventors:
- Santa Clara CA, US
Naamah ARGAMAN - San Jose CA, US
David SELL - Santa Clara CA, US
Ludovic GODET - Sunnyvale CA, US
International Classification:
G03F 7/20
G03F 7/00
Abstract:
Methods of fabricating large-scale optical devices having sub-micron dimensions are provided. A method is provided that includes projecting a beam to a mask, the mask corresponding to a section of an optical device pattern, the optical device pattern divided into four or more equal portions, each portion corresponding to a section of a substrate. The method further includes scanning the mask over a first section of the substrate to pattern a first portion of the optical device pattern, the substrate is positioned at a first rotation angle relative to the mask. The method further includes rotating the substrate to a second rotation angle, the second rotation angle corresponding to 360 divided by a total number of portions of the optical device pattern, scanning the mask over a second section of the substrate from the initial position to the final position to pattern a second portion of the optical device pattern.
