James A Chambers, Age 874 Sparrow Ln, Bedford, NH 03110

4720871, Jan 19, 1988

Jun 13, 1986

6/873903

James M. Chambers - Carlsbad CA

Hughes Aircraft Company - Los Angeles CA

G06K 936
G06F 15336

382 42

A method and apparatus for processing digital data representative of a digital array of points of a source image including a source image memory (12) or digitized camera (40) for providing a source image as a digital array of points, with provision for generating an end of array, or end of frame signal, (32) each time that the array has been computationally adjusted and transferred to a destination image memory. A control processor (14) includes a convolution kernel algorithm having the elements thereof configured for establishing a computational sequence or offset (18, 10) for each point in the array relative to a reference point, with each element having a constant value for computational adjustment of the array for each frame time represented by that element. The computational logic (21, 22, 24) is responsive to the control processor (14) for mathematically manipulating each point of the source image digital array for transfer to the destination image memory (14) in a position spatially related to the source image array. Each end of array signal enables the control processor to reset to the next element of the convolution kernel to establish a new constant and new offset for subsequent iterative computational processing, and combining with the adjusted value in the destination image memory (24), with the total number of iterations determined by the number and values of the computational values whereby the source image array is transformed into an array of digital values in the destination image memory representative of a convolved image.

5626410, May 6, 1997

Sep 20, 1995

8/530856

James M. Chambers - Carlsbad CA
Steven E. Shields - San Diego CA

Palomar Technologies Corporation - Carlsbad CA

G03B 2114

353 94

A novel rear projection screen that displays images with substantially uniform brightness over a wider field-of-view than prior rear projection screens, comprising a first diffusing assembly for diffusing the image and a second diffusing assembly for further diffusing the image from the first diffuser. In the preferred embodiment, the first and second diffusing assemblies comprise an input diffusing screen and a fiber optic array, respectively, with an output diffusing screen used at the output end of the fiber optic array. A preferred flat panel tiled display system that incorporates the present invention includes a plurality of collimated light sources, with respective liquid crystal display assemblies that impart images onto the collimated light beams. An imager images the image-bearing light beams onto the rear projection screen described above so that they are displayed in a tiled arrangement.
