James J Cronmiller, Age 4526 Valley Green Dr, Penfield, NY 14526

D615443, May 11, 2010

Jan 27, 2009

29/313620

R. Michael Datz - Rochester NY, US
James J. Cronmiller - West Henrietta NY, US

Star Headlight & Lantern Co., Inc. - Avon NY

1005

D10120

8193928, Jun 5, 2012

Dec 12, 2008

12/316506

James J. Cronmiller - West Henrietta NY, US
Oriana J. Starr - Rochester NY, US

Star Headlight & Lantern Co., Inc. - Avon NY

B60Q 1/26

340474, 340463, 340465, 340475

Apparatus for controlling visible and audible warning signals, particularly signals from light bars, traffic director lighting, and siren and public address outputs for police and emergency vehicle applications, is provided in a single unit. Mounted in a chassis of the unit in layered relationship are a siren board and a relay board. The siren board contains amplifier and associated circuitry for generating and amplifying siren signals, and for providing microphone signals and signals from a 2-way radio of the vehicle, to a speaker which projects these audible signals for warning of and controlling emergency conditions. The relay board contains circuitry for switching power from the vehicle battery to the traffic director lighting and warning lighting (as may be provided by light bars) mounted on or in the vehicle. A microcontroller switches the lighting to the selected lighting units via relays on the board. A controller utilizing buttons providing a keypad, rotary and slide switches, is mounted on the chassis at one end thereof to provide manual access to the police or other emergency personnel for controlling the lighting and the siren, as well as public announce and radio audible signals.

8265320, Sep 11, 2012

Jan 27, 2009

12/321922

R. Michael Datz - Rochester NY, US
James J. Cronmiller - Rochester NY, US

Star Headlight & Lantern Co., Inc. - Avon NY

H04R 1/20

381341, 381342

A loudspeaker for projecting siren and other warning signals which is compact to facilitate installation in emergency vehicles, and which provides a horn projector in the compact space. The loudspeaker has a support in which an electrically driven driver unit is mounted. A chamber providing a plurality of cyclonic or spiral paths for sound from the speaker is located at one end of the support as by being connected to the support or being a part thereof. The support has a plurality of passageways for sound from each of the paths to exit ports at an end of the support opposite to the end thereof attached to or having the chamber. The cyclonic paths and the passageways are of like length and taper so that the sound from the exit ports combined in reinforcing relationship and projects outwardly from the exit port end of the support. The support provides a recombiner for the sound propagating along the cyclonic paths and passageways to provide the effect of a long horn in the compact space.

8278826, Oct 2, 2012

Dec 12, 2008

12/316527

James J. Cronmiller - West Henrietta NY, US

Star Headlight & Lantern Co., Inc. - Avon NY

B60Q 1/26

315 80, 315291, 315295, 315312, 315 77

A multimode controller for LED light sources, especially sources in warning lights, such as light bars, provides for a temporary increase in brightness from the LEDs by providing a burst mode, in addition to a flashing mode and a continuous mode. The modes are carried out by programming a microprocessor which receives signals from control switches, which may be pressed and released. The programming precludes the burst mode to continue for longer than a predetermined time thereby ensuring that the power does not exceed the LEDs damage threshold characteristic. The controller thereby provides for temporary bursting to make visible the region in front of or around an emergency vehicle for a short period of time without the need for light sources dedicated solely to the high intensity brightness mode of operation of a warning light system.

2012005, Mar 1, 2012

Aug 24, 2010

12/806908

James J. Cronmiller - West Henrietta NY, US

H04R 25/00

381150

A backup alarm for producing an audible warning signal which warbles or beeps, at selected audible output power (Db) levels includes a computer which drives a speaker by switching drive voltage to the speaker with above audible, high frequency pulses in packets repetitive at audible frequency. The high frequency pulses are pulse width modulated at different ratios selected from tables in memory of the computer in accordance with the voltage from a battery power source which provides the drive voltage so that the audible output power remains constant at the selected level over a wide range of power source voltage. By providing for warning/alarm signal generation by means of an operating system which provides both high, above audible frequency and audible frequency switching, power conservation and warning signal output power control are accomplished without interference.

D574799, Aug 12, 2008

Jan 30, 2008

29/294850

James J. Cronmiller - West Henrietta NY, US
Oriana J. Starr - Rochester NY, US

Star Headlight & Lantern Co., Inc. - Avon NY

1403

D14137, D14257, D14258, D10102

2014029, Oct 2, 2014

Mar 5, 2014

14/198305

- AVON NY, US
JAMES CRONMILLER - HENRIETTA NY, US
MICHAEL A. BARBATO - WEBSTER NY, US

B60Q 1/26

362521, 362546

A system is provided for mounting a lamp having a plurality of different types of mounting members. One of the mounting members is a rigid tray mountable by fasteners flush upon a surface of a vehicle to enable an on-surface mounting mode, and other of said mounting members, such as a grommet or bracket, are mountable at least partially in an opening or hole when present along such surface of a vehicle to enable an inset mounting mode. The different mounting members each engage a common shape housing of the lamp, such as round or oval, so that by selection of one of the mounting members, on-surface or inset mounting of the lamp can readily be achieved. One or more common engagement features are provided along the housing to facilitate engagement of the housing of the lamp by mounting members in on-surface and inset mounting modes.
