Jeremy T Keegan, Age 43Franksville, WI

7893804, Feb 22, 2011

Jun 27, 2007

11/823394

Abdolmehdi Kaveh Ahangar - Brown Deer WI, US
Jeremy J. Keegan - Kewaskum WI, US

Rockwell Automation Technologies, Inc. - Mayfield Heights OH

H01F 27/08

336 60

Provided is an electrical apparatus comprising a magnetic core, a conductive coil wound around at least a part of the core, a cooling element configured to receive a cooling fluid to cool the core and the coil during operation, and at least one biasing element operatively associated with the core to urge the core and the coil into engagement with the cooling element despite differential expansion or contraction of the core and the coil and manufacturing tolerances. Further provided is a method for making an electrical apparatus comprising disposing a conductive coil wound around at least a part of a magnetic core, disposing a cooling element between the core and the coil, the cooling element configured to receive a cooling fluid to cool the core and the coil during operation, and urging the core and the coil into engagement with the cooling element despite differential expansion or contraction of the core and the coil and manufacturing tolerances.

8009004, Aug 30, 2011

Feb 18, 2011

13/030255

Abdolmehdi Kaveh Ahangar - Brown Deer WI, US
Jeremy J. Keegan - Kewaskum WI, US

Rockwell Automation Technologies, Inc. - Mayfield Heights OH

H01F 27/08

336 60

Provided is an electrical apparatus comprising a magnetic core, a conductive coil wound around at least a part of the core, a cooling element configured to receive a cooling fluid to cool the core and the coil during operation, and at least one biasing element operatively associated with the core to urge the core and the coil into engagement with the cooling element despite differential expansion or contraction of the core and the coil and manufacturing tolerances. Further provided is a method for making an electrical apparatus comprising disposing a conductive coil wound around at least a part of a magnetic core, disposing a cooling element between the core and the coil, the cooling element configured to receive a cooling fluid to cool the core and the coil during operation, and urging the core and the coil into engagement with the cooling element despite differential expansion or contraction of the core and the coil and manufacturing tolerances.

8081462, Dec 20, 2011

Sep 13, 2007

11/854818

John A. Balcerak - Muskego WI, US
Scott D. Day - Richfield WI, US
Jeremy J. Keegan - Kewaskum WI, US
William K. Siebert - West Bend WI, US
Neil Gollhardt - Fox Point WI, US

Rockwell Automation Technologies, Inc. - Mayfield Heights OH

H05K 7/20
H02B 1/00
H01F 27/08
F28F 7/00
F28D 15/00

361701, 361699, 361676, 336 61, 16510433, 165 804

A method and kit of components for configuring electronics cooling configurations, the kit comprising a plurality of passageway forming members, each forming member including an extruded member having first and second ends and forming at least one passageway and at least one of an input port and an output port that opens into the passageway, each forming member also including at least one plug insert secured to the second end of the forming member to block the at least one passageway, a plurality of elastomeric seals, a plurality of mechanical fasteners, wherein forming members can be arranged adjacent each other with ports aligned and the fasteners can be used to mechanically fasten the forming members together with seals there between to form various cooling configurations.

2012008, Apr 12, 2012

Dec 19, 2011

13/330058

John A. Balcerak - Muskego WI, US
Jeremy J. Keegan - Kewaskum WI, US
William K. Siebert - West Bend WI, US
Neil Gollhardt - Fox Point WI, US
Scott D. Day - Richfield WI, US

F28F 1/00

165177

Cooling systems include a first passageway forming member that includes first and second ends and at least one connecting recess that opens into first and second passageways formed by the first passageway forming member. A second passageway forming member includes first and second ends and inlet and outlet ports proximate the first end such that the first end, including an elastomeric seal and the inlet and outlet ports, is sealably insertable in and removable from the at least one connecting recess, where the inlet port opens into the first passageway and the outlet port opens into the second passageway, and where, when the first end is inserted in the at least one connecting recess, the elastomeric seal is sandwiched between and in substantial contact with both the first end and the first passageway forming member.

2013011, May 16, 2013

Jul 13, 2012

13/548753

Bruce W. Weiss - Milwaukee WI, US
Doyle F. Busse - Muskego WI, US
Jeremy J. Keegan - Kewaskum WI, US
Lixiang Wei - Whitefish Bay WI, US
Michael W. Loth - Germantown WI, US
Rangarajan M. Tallam - Germantown WI, US
Yogesh Patel - Grafton WI, US

Rockwell Automation Technologies, Inc. - Mayfield Heights OH

H02H 7/125
H02P 27/04

3184003, 363 53

AC pre-charging techniques are provided for pre-charging the DC bus on a motor drive. AC pre-charging techniques involve pre-charge circuitry including a manual switch, an automatic switch, and pre-charge control circuitry to switch the automatic switch between pre-charge and pre-charge bypass modes in response to an initialized pre-charge operation, input voltage sags, etc. In some embodiments, the pre-charge operation may be initialized by switching the manual switch closed. In some embodiments, the pre-charge operation may also be initialized by a detected voltage sag on the DC bus. The pre-charge circuitry may also be configured to disconnect a motor drive from the AC power supply under certain fault conditions.

2013012, May 16, 2013

Jul 13, 2012

13/548685

Bruce W. Weiss - Milwaukee WI, US
Doyle F. Busse - Muskego WI, US
Jeremy J. Keegan - Kewaskum WI, US
Lixiang Wei - Whitefish Bay WI, US
Michael W. Loth - Germantown WI, US
Rangarajan M. Tallam - Germantown WI, US
Yogesh Patel - Grafton WI, US

Rockwell Automation Technologies, Inc. - Mayfield Heights OH

H02M 7/537

363131

Systems and methods are provided for pre-charging the DC bus on a motor drive. Pre-charging techniques involve pre-charge circuitry including a manual switch, an automatic switch, and pre-charge control circuitry to switch the automatic switch between pre-charge and pre-charge bypass modes in response to an initialized pre-charge operation, input voltage sags, and so forth. In some embodiments, the pre-charge operation may be initialized by switching the manual switch closed. In some embodiments, the pre-charge operation may also be initialized by a detected voltage sag on the DC bus. The pre-charge circuitry may also be configured to disconnect to isolate a motor drive from the common DC bus under certain fault conditions.

2014005, Feb 27, 2014

Aug 13, 2013

13/965766

Steven Kaishian - Wauwatosa WI, US
Jeremy Keegan - Kewaskum WI, US
Yogesh Popatlal Patel - Grafton WI, US
Bruce W. Weiss - Milwaukee WI, US

ROCKWELL AUTOMATION TECHNOLOGIES, INC. - Mayfield Heights OH

H01B 5/02

174 682

An electrical bus assembly includes a frame and a plurality of bus bar carriers connected to the frame. The bus bars are supported by the bus bar carriers in parallel spaced-apart relation. A first retainer cap is secured to a first one of the plurality of bus bar carriers located adjacent a first end of the frame. A second retainer cap is secured to a second one of the plurality of bus bar carriers located adjacent a second end of the frame. The first and second retainer caps limit axial movement of the bus bars relative to the plurality of carriers sufficiently to prevent escape of the bus bars from the carriers. A bus bar connector is also disclosed for supplying power to or from the bus bars. An electrical bus system includes a first and second bus bar assemblies and a jumper connector assembly.

2015025, Sep 10, 2015

May 26, 2015

14/721814

- Mayfield Heights OH, US
Doyle F. Busse - Muskego WI, US
Jeremy J. Keegan - Kewaskum WI, US
Lixiang Wei - Whitefish Bay WI, US
Michael W. Loth - Germantown WI, US
Rangarajan M. Tallam - Germantown WI, US
Yogesh Patel - Grafton WI, US

H02P 6/20
H02P 6/00
H02P 6/04
H02M 7/537

Systems and methods are provided for pre-charging the DC bus on a motor drive. Pre-charging techniques involve pre-charge circuitry including a manual switch, an automatic switch, and pre-charge control circuitry to switch the automatic switch between pre-charge and pre-charge bypass modes in response to an initialized pre-charge operation, input voltage sags, and so forth. In some embodiments, the pre-charge operation may be initialized by switching the manual switch closed. In some embodiments, the pre-charge operation may also be initialized by a detected voltage sag on the DC bus. The pre-charge circuitry may also be configured to disconnect to isolate a motor drive from the common DC bus under certain fault conditions.
