Jerome M Meyer Deceased19755 Hillside St, Excelsior, MN 55331

7274213, Sep 25, 2007

May 5, 2005

11/123498

Jerome M. Meyer - Chanhassen MN, US
Scott A. Davidson - Savage MN, US

Xilinx, Inc. - San Jose CA

G06F 7/38

326 41, 326 37, 326 38, 326 39, 326 40

A dedicated protocol generation unit provides the ability to detect validity of data received from a configurable logic block, such as a programmable logic device (PLD). Data valid signaling is provided by the configurable logic block, such that invalid data received from the configurable logic block is replaced with programmable insertion data prior to transmission, while valid data is allowed to be transmitted without replacement. Also, data received by Input/Output (I/O) portions of the dedicated protocol generation unit are compared to programmable data patterns. After a positive comparison, matching data is either truncated and not delivered to the configurable logic block, or the matching data is delivered to the configurable logic block with appropriate data valid signaling.

7346079, Mar 18, 2008

Apr 20, 2004

10/829037

Jerome M. Meyer - Chanhassen MN, US

Xilinx, Inc. - San Jose CA

H04J 3/00
H04J 3/16
H04J 3/22
H04J 3/24
H04J 3/07

370476, 370470, 370472, 370473, 370506

Methods and structures of performing multi-level comma detection and alignment on an unaligned data stream. Each string of N consecutive bits in the unaligned data stream is monitored for a predetermined byte value. When the predetermined byte value is located, the unaligned data stream is aligned with the predetermined byte value, producing a partially aligned data stream. A string of bytes from the partially aligned data stream is then compared with a predetermined sequence of byte values. When the predetermined sequence is located, the partially aligned data stream is aligned based on the location of the predetermined sequence within the partially aligned data stream. The invention also encompasses multi-level comma detection and alignment circuits that can perform, for example, the previously described inventive methods.

7346794, Mar 18, 2008

Jan 21, 2005

11/040423

Scott Allen Davidson - Savage MN, US
Jerry Chuang - Sunnyvale CA, US
David E. Tetzlaff - Minnetonka MN, US
Jerome M. Meyer - Chanhassen MN, US

Xilinx, Inc. - San Jose CA

G06F 1/12
G06F 7/00
G06F 1/04
G06F 1/00

713400, 713500, 713503, 713600

A method and apparatus for providing clock phase alignment in a transceiver system are disclosed. Circuits are provided for providing clock phase alignment to adjust and align the phase between clock domain boundaries and for maintaining alignment of multiple outputs signals.

2003010, May 29, 2003

Nov 27, 2001

09/995410

Scott Sarkinen - Mounds View MN, US
Jeffrey Swart - Eden Prairie MN, US
Neil Schlegel - Lino Lakes MN, US
Jerome Meyer - Chanhassen MN, US
David Hollinrake - Brooklyn Park MN, US

Terago Communications, Inc. - Maple Grove MN

G06F017/50

716/012000

A system and method for interfacing network elements using an isolated fabric interface module, which is facilitated through exploitation of standards otherwise not specified for the particular networking functions in which they are utilized. Fabric interface functionality is isolated and independent of line and switch fabric cards. Standards otherwise suitable for use in interfacing network elements are adapted for use in the isolated fabric interface configuration. The standard interfaces are adapted to extend beyond the specified length, signal traces are routed according to predetermined routing rules using matched impedance connectors, and signals are terminated to facilitate the length extension. Standard system controllers may also be used although the controlled line cards are not compliant with the standard. A network switching/routing element having a discrete fabric interface module can thus be designed using known standards, while effectively allowing the standards to operate at non-specified parameters.
