Inventors:
Theodore Diaz - Houston TX, US
Edmundo Isas - Baytown TX, US
Jose Oliver - Houston TX, US
International Classification:
G03B021/00
Abstract:
The Prosy, a fully scaleable and customize video player projection system with an extension of using a computer via local area network and broadband wireless is installed on a wooden utility pole () set at forty feet from an existing billboard to project full motion video commercials continuously at night The video player (), the use of a computer via local area network and broadband wireless as an extension of the projection system and the projector () are the primary components of the systems, these components operate by a time selector to activate and deactivate at certain hours To energize the system, a twenty-amp breaker that is located at the existing billboard is considered for power source The components have an incapability of operating outdoors therefore, a humidity and temperature system is installed to protect it from heat, humidity, and cold weather. A nitrogen bottle (A) is the main supply of air circulation to prevent any moisture inside each enclosure () To keep each enclosure () cool, electric fans () are installed. To better service and record the temperature readings, a temperature controller () is installed inside each aluminum junction box () to protect it from rain or any flying debris With the provisional application that was filed the system was able to be enhance to give better service.
