6634386, Oct 21, 2003

Oct 2, 2001

09/969543

Brian Maloney - Allen Park MI
John Cassidy - Brighton MI
Joseph A. Starr - Plymouth MI

Kelsey-Hayes Company - Livonia MI

F16L 5504

138 31, 138 30, 303DIG 11

A hydraulic control unit (HCU) for a vehicle brake system having an HCU body and an accumulator mounted in the HCU body. A grommet is provided for mounting the HCU body to a vehicle body and resiliently separating the HCU body from the vehicle body. The grommet defines a vent path for the accumulator and includes a hollow generally cylindrical shaft. The shaft has a closed end and an open end, and the closed end has an opening therethrough. An enlarged annular head is formed on the open end of the shaft and has an inner surface defining an axial bore therethrough. The axial bore is in fluid communication with the hollow shaft, the annular head further has a crown cut geometry providing radially extending grooves within an axial face of the annular head, the radially extending grooves being in fluid communication with the axial bore of the annular head.

7182413, Feb 27, 2007

Aug 5, 2003

10/634529

Joseph A. Starr - Plymouth MI, US
Eric R. Kaye - Livonia MI, US

Kelsey-Hayes Company - Livonia MI

B60T 8/36

3031192, 25112902

A valve seat assembly for a control valve of a vehicle brake system includes a valve seat body. A valve passageway extends through a portion of the valve seat body. A groove is formed circumferentially in an outer surface of the valve seat body. The groove defines a groove surface substantially parallel to an axis of the valve body. A bore extends between the groove surface and the valve passageway to provide fluid communication between the groove surface and the valve passageway. A substantially resilient seal is disposed in the groove of the valve seat body.

2012013, May 31, 2012

Aug 11, 2010

13/388133

Joseph F. Zeoli - Livonia MI, US
Blaise Ganzel - Ann Arbor MI, US
Thomas Wald - Hollnich, DE
Richard A. Swarich - Plymouth MI, US
Robert I. Girkin - New Hudson MI, US
Joseph A. Starr - Plymouth MI, US
David Lopez-Larequi - Koblenz, DE

KELSEY-HAYES COMPANY - Livonia MI

B60T 8/1755

303 11

A vehicle braking system includes a slip control system operable in an electronic stability control (ESC) mode to automatically and selectively apply the brakes in an attempt to stabilize the vehicle when an instability condition has been sensed. The slip control system is further operable in an adaptive cruise control (ACC) mode to automatically apply the brakes to slow the vehicle in response to a control signal. The slip control system includes a variable speed motor drive piston pump for supplying pressurized fluid pressure to the brakes through a valve arrangement. In the ESC mode, the pump motor operates in an ESC speed range, and in the ACC mode, the pump motor operates in an ACC speed range lower than the ESC speed range. The slip control system further includes an attenuator connected to a pump outlet for dampening pump output pressure pulses prior to application to the brakes. The attenuator includes an elastomeric member located in an attenuator chamber of a housing. The attenuator chamber defines a shoulder and the elastomeric member includes a flange which rests on the shoulder and locates the elastomeric member in a predetermined axial position within the attenuator chamber. An outside wall of the elastomeric member includes circumferentially extending grooves defining ribs between adjacent grooves.

2014000, Jan 2, 2014

Mar 15, 2013

13/843736

LUCAS AUTOMOTIVE GMBH - , US
Georg Kedak - Thuer, DE
Joseph F. Zeoli - Livonia MI, US
Joseph A. Starr - Plymouth MI, US
William P. Caldwell - South Lyon MI, US
Richard A. Swarich - Plymouth MI, US

KELSEY-HAYES COMPANY - Livonia MI
LUCAS AUTOMOTIVE GMBH - Koblenz

F15B 1/04

138 30

A damping element for attenuating hydraulic pressure pulses is integrated into a hydraulic chamber of a motor vehicle hydraulic system. The damping element includes a end cap support body and a membrane that fits over a portion of the support body. The membrane has a first side facing towards a source of hydraulic fluid and a second side facing away from the hydraulic fluid source. At least one space is provided between the second side of the membrane and the end cap support body to allow for deformation of the membrane under hydraulic pressure. The membrane has a collar with a lip seal provided for fitting into place on the wall of the hydraulic chamber. At least one second space for receiving hydraulic fluid is defined between the lip seal and a region of the membrane opposite the lip seal.

5524904, Jun 11, 1996

Nov 10, 1994

8/337548

Gary A. Willi - Ann Arbor MI
Joseph A. Starr - Plymouth MI
William Doyle - Chelsea MI
Gary Knight - Woodhaven MI

Kelsey-Hayes Company - Livonia MI

F16J 1532

277152

A lip seal having an annular body, a contiguous annular shoulder extending axially therefrom, and a contiguous annular seal lip extending coaxially from the body and flaring away from the shoulder. Strengthening ribs extend axially along the shoulder, the shoulder is undercut to provide space into which areas of the annular seal lip can escape, with each such feature thereby promoting nonuniform deformation of the annular seal lip, ensuring a path for fluid to flow, and thereby minimizing the possibility of a seal lock-up condition occurring when pressure is applied to the back of the lip seal during brake release. Flow ribs axially coextensive with the strengthening ribs also extend along the body to create fluid flow paths therebetween. The radial dimensions of the lip seal are also reduced to allow a valve cartridge of given diameter to function in a smaller housing bore than that required when a conventional lip seal is used, thus facilitating the downsizing of a control valve module in which the valve cartridge is to be used.

6203117, Mar 20, 2001

Oct 19, 1998

9/174870

Joseph A. Starr - Plymouth MI
Ronald L. Sorenson - Erie MI

Kelsey-Hayes Corporation - Livonia MI

B60T 1708

303 87

A hydraulic control unit of an electronically-controlled vehicular brake system includes a housing having a bore. The bore is in fluid communication with a first fluid passage leading to an outlet of a pump. The bore is also in fluid communication with a second fluid passage leading to a master cylinder. A retainer cap is mounted in the bore. A piston is slidably received in the retainer cap. The piston includes a fluid channel providing fluid communication between the first and second fluid passages. A spring is positioned between the retainer cap and the piston to urge the piston from the retainer cap. A check valve assembly is mounted in the fluid channel of the piston that permits only one-way fluid flow from the first fluid passage to the second fluid passage. The compensator assembly provides a controlled amount of additional displacement of a master cylinder piston when the brake system is operating in an electronically activated mode only.

2014020, Jul 24, 2014

Jan 21, 2013

13/746026

- Livonia MI, US
Joseph A. Starr - Plymouth MI, US

Kelsey-Hayes Company - Livonia MI

F04B 19/00
B60T 13/16

303 601, 417437

A vehicular hydraulic braking pump includes a sleeve having an inner bore defining an inner bore surface and a piston having a stop collar and a ramped seal face. The stop collar, ramped seal face, and the inner bore cooperating to define a seal pocket which traps a high pressure seal therein. The ramped seal face provides contact of the high pressure seal to the sleeve inner bore that is proportional to fluid pressure acting on the high pressure seal.
