Lennart S Nilsson, Age 67928 Arabian Ave, Winter Springs, FL 32708

5798595, Aug 25, 1998

Dec 30, 1996

8/777560

Lennart S. Nilsson - Winter Springs FL
Charles M. Rowe - Orlando FL
Donald Yaffee - Winter Springs FL

Westinghouse Electric Corporation - Pittsburgh PA

H02K 346

310260

A vibrational control system for the coils of a stator includes a coil support bracket affixed to the stator, a coil support brace mounted on the coil support bracket with a shim arranged between the coil support brace and the coil support bracket, a push block arranged between the coils and the coil support brace, and control structure for controlling the vibrations of the stator coils.

4618795, Oct 21, 1986

Apr 10, 1985

6/721618

Glenn D. Cooper - Orlando FL
John M. Butler - Orlando FL
Darrell R. Morrison - Orlando FL
Charles L. Senic - Winter Park FL
Lennart S. Nilsson - Winter Park FL
Charles M. Rowe - Orlando FL

Westinghouse Electric Corp. - Pittsburgh PA

H02K 346

310260

A structure for consolidating large turbine generator end turns while providing for thermal compensation includes a decoupled brace that is located radially outside the end turns and has a bottom piece secured to a bracket secured to the core as well as a top piece adjacent the coil and an intermediate decoupler between the two that includes elastomeric material for cushioning as well as a slip layer for allowing free axial movement between the top and bottom pieces of the brace. Additionally, keyed strain blocks may be utilized between top and bottom coils of the assembly for greater consolidation.

4894575, Jan 16, 1990

Nov 7, 1988

7/268103

Lennart S. Nilsson - Winter Springs FL
John M. Butler - Orlando FL
Hector O. Ponce - Pensacola FL
Darrell R. Morrison - Orlando FL

Westinghouse Electric Corp. - Pittsburgh PA

H02K 346
H02K 350
H01R 428

310260

An electrical generator connection, to connect coil ends, and a method of making the same. A header cap having a spherically shaped portion is brazed to each coil end to be connected. A pair of connector bars, each having a pair of similarly sized spherical seats, receives the spherical portion of each coil end header cap. Electrical and mechanical connection is provided by bolting the two connector bars together.
