Melvin Allen Olson Deceased4481 Genova Rd, Rancho Cucamonga, CA 91701

6899297, May 31, 2005

Dec 22, 1995

08/577992

Richrad J. Sand - Torrance CA, US
Michael L. Wells - Hawthorne CA, US
Melvin A. Olson - Rancho Cucamonga CA, US
Eric B. Sutton - Los Angeles CA, US

Raytheon Company - Waltham MA

F41G007/32

244 312, 365153

The need in the art is addressed by the improved missile fire control system of the present invention. In the illustrative embodiment, the inventive system is adapted for use with TOW missile systems and includes a telescope cluster assembly () for generating target position signals (). A digital error detector (′) receives and processes target position signals () from the telescope cluster assembly (). The processed signals () are then fed to a stabilization control amplifier (), where a microcontroller () steps through a set of instructions eliminate angular noise from the target position signals (). The stabilization control amplifier () subsequently provides feedback to the telescope cluster assembly () for adjusting the line-of-sight in the telescope cluster assembly (). Software instructions for the microcontroller () and constant reference data are stored in the microcontroller memory (not shown). An erasable programmable logic device () is used to output discreet signals for controlling mirror positioning.
