Miao YuChicago, IL

2014007, Mar 20, 2014

Sep 19, 2012

13/622434

Shaojun ZHOU - Palatine IL, US
Miao YU - Pittsford NY, US
Moises A. CARREON - Louisville KY, US

GAS TECHNOLOGY INSTITUTE - Des Plaines IL

B01D 71/70
B01D 71/56
B01D 71/64
B01D 71/16
B01D 53/22
B01D 71/68
B82Y 30/00

96 12, 96 11, 977778

An apparatus for gas separation a composite gas separation membrane having a gas separation layer disposed on a surface of a porous support. The gas separation layer has a plurality of gas permeable inorganic nano-particles embedded in a dense polymer forming substantially only discrete gas transport channels through the dense polymer layer, wherein direct fluid communication is provided from a feed side of the composite gas separator membrane to the porous support. Preferably, the inorganic nano-particles are porous molecular sieve particles, such as SAPO-34, ALPO-18, and Zeolite Y nano-particles.

2016009, Apr 7, 2016

Sep 30, 2015

14/870906

Shiguang LI - Mount Prospect IL, US
Shaojun Zhou - Palatine IL, US
Howard S. Meyer - Hoffman Estates IL, US
Miao Yu - Pittsford NY, US

C01B 13/02
B01D 11/04

A highly cost-efficient method and process for producing oxygen from a gaseous mixture such as air results in substantial energy savings compared to conventional methods. The gaseous mixture is fed to a membrane absorber in which oxygen from the gas is absorbed, through a first membrane by an oxygen-absorbing liquid that possesses suitable absorption and desorption properties. The resulting oxygen-rich carrier liquid is fed to a membrane desorber in which oxygen from the liquid is desorbed through a second membrane, suitably with the aid of a vacuum. The oxygen product suitably has greater than 95% purity, or greater than 99% purity.

2015030, Oct 29, 2015

Apr 25, 2014

14/262161

SHIGUANG LI - Mount Prospect IL, US
Shaojun Zhou - Palatine IL, US
Howard S. Meyer - Hoffman Estates IL, US
Miao Yu - Pittsford NY, US
Moises A. Carreon - Boulder CO, US

F17C 11/00
B01J 20/22
B01J 20/20
B01J 20/28
B01J 20/16

Adsorbent pellets coated with an outer nano-porous layer can be loaded with gas at loading pressures of 250 bar or greater, enabling a much higher loading than can be achieved at low pressures. The nano-porous layer provides nano-valves which can be sealed with an adsorbate such as ethanol or a hydrocarbon to close the nano-valves. The closed nano-valves maintain the high loading pressure inside the adsorbent pellets, and thus maintain the gas loading, during storage of the loaded nano-valved adsorbent pellets at much lower pressure. To release the gas, the nano-porous layer can be heated to a temperature sufficient to vaporize the adsorbate and open the nano-valves.

2015004, Feb 12, 2015

Aug 9, 2013

13/963677

Shiguang LI - Mount Prospect IL, US
Shaojun ZHOU - Palatine IL, US
Miao YU - Pittsford NY, US

C07C 67/56

560218

A method for separating the components of a mixture containing methyl methacrylate, water, and methanol in which the mixture is dehydrated in a first stage membrane unit, producing a dehydrated mixture. Methanol in the dehydrated mixture is removed in a second stage membrane unit, producing a retentate stream containing methyl methacrylate and substantially no said methanol.
