Michael F Scalise, Age 7010755 Manor Wood, Clarence, NY 14031

7709158, May 4, 2010

Dec 18, 2006

11/612148

Carl R. Schlaikjer - Middleboro MA, US
Michael F. Scalise - Clarence NY, US

Electrochem Solutions, Inc. - Clarence NY

H01M 6/16

429339, 429188

The present invention is directed to ambient temperature molten salts as non-aqueous electrolytes. The molten salts comprise a cation of a guanidine moiety and an anion. The guanidine cation is asymmetrically halogenated, which means that in the general formula: C(NR), one or two, but not all three, of the N atoms are bonded to R radicals that are the same for each thusly substituted N atom and the third N atom is bonded to hydrogen or two of the same R radicals, and if R radicals, they are different than the R radicals bonded to the first and second N atoms. The R radicals bonded to any one N atom is an alkyl group of from 1 to 4 carbon atoms. Either both of the hydrogen atoms or at least one of the hydrogen atoms on each of the R radicals bonded to one or two, but not three, of the N atoms are substituted with the same halogen selected from the group consisting of fluorine, chlorine, bromine, and iodine. Preferably the anion is partially or fully halogenated, and the halogen of the guanidinium cation and that of the anion are the same. The electrolyte is useful with electrochemical devices such as primary and secondary electrochemical cells and capacitors, such as of the electrolytic and electrolytic/electrochemical hybrid types.

2018025, Sep 13, 2018

Mar 7, 2017

15/451444

- Chaska MN, US
Jeanne Douglas - Shakopee MN, US
Andrew Senn - Chanhassen MN, US
Michael F. Scalise - Clarence NY, US

A61M 25/09

The core element for a guidewire comprises a proximal stainless steel portion and a distal nitinol portion. The distal nitinol portion comprises a proximal segment of an at least partially linear elastic nitinol and a distal segment of a super elastic nitinol. The proximal end of a first spring coil contacts the super elastic nitinol with the first spring coil distal end being proximal the distal end of the distal segment of the super elastic nitinol. A second spring coil has a proximal portion that contacts the first spring coil distal end at a spring coil connection. Further, the second spring coil extends distally to an atraumatic tip. Extending radially from a longitudinal axis of the core wire, the first and second spring coils are spaced from and circumferentially unsupported by the distal nitinol core portion at the spring coil connection.

2017029, Oct 12, 2017

Jun 21, 2017

15/628741

- Clarence NY, US
Keith W. Seitz - Clarence Center NY, US
Michael F. Scalise - Clarence NY, US

A61N 1/375
H01R 13/719
H01R 13/52
H01G 4/35
H01R 13/426

A feedthrough filter capacitor assembly comprising a terminal pin connector is described. The terminal pin connector is designed to facilitate an electrical connection between the terminal pin comprising a multitude of compositions to a circuit board of an implantable medical device. The terminal pin connector comprises a clip portion positioned within a connector housing. The connector clip mechanically attaches to the terminal pin of the feedthrough with at least one prong and an exterior surface of the connector housing electrically contacts the circuit board, creating an electrical connection therebetween. The connector housing comprises a material that is conducive to a weld or solder attachment process to the circuit board. The feedthrough filter capacitor assembly is particularly useful for incorporation into implantable medical devices such as cardiac pacemakers, cardioverter defibrillators, and the like, to decouple and shield internal electronic components of the medical device from undesirable electromagnetic interference (EMI) signals.

2015029, Oct 15, 2015

Jun 23, 2015

14/747582

- Clarence NY, US
Keith W. Seitz - Clarence Center NY, US
Michael F. Scalise - Clarence NY, US

H01R 13/52
A61N 1/375
H01R 43/00
H01R 43/20
H01G 4/35

A feedthrough filter capacitor assembly comprising a terminal pin connector is described. The terminal pin connector is designed to facilitate an electrical connection between the terminal pin comprising a multitude of compositions to a circuit board of an implantable medical device. The terminal pin connector comprises a clip portion positioned within a connector housing. The connector clip mechanically attaches to the terminal pin of the feedthrough with at least one prong and an exterior surface of the connector housing electrically contacts the circuit board, creating an electrical connection therebetween. The connector housing comprises a material that is conducive to a weld or solder attachment process to the circuit board. The feedthrough filter capacitor assembly is particularly useful for incorporation into implantable medical devices such as cardiac pacemakers, cardioverter defibrillators, and the like, to decouple and shield internal electronic components of the medical device from undesirable electromagnetic interference (EMI) signals.
