Paul F Christie, Age 54689 8Th Ave UNIT 3R, New York, NY 10036

5602679, Feb 11, 1997

Feb 6, 1995

8/384724

Eugene Dolgoff - Westbury NY
Malcolm J. MacFarlane - Brookfield CT
Paul B. Christie - New York NY

Projectavision, Inc. - New York NY

G02B 2712
G09G 300
H04N 931

359640

A light valve such as an active matrix LCD between crossed polarizers, utilizing, for instance, individual transistors to control each "pixel area" of the LCD and storage elements to store video signal data for each pixel, with optically shielded "dead spaces" between pixels to eliminate electric field cross-talk and non-information-bearing light bleed-through, is illuminated with a bright independent light source which creates a video image projected via specialized projection optics onto an internal or external screen without distortions, regardless of the angle of projection onto the screen. Use of heat sinks, IR reflective coatings, heat absorbing optics, optional fluid and a thermistor controlled pixel transistor bias voltage injection servo circuit stabilizes image performance, maintaining accurate color and contrast levels as the LCD changes temperature. In one embodiment of the invention, use of a multi-color LCD with a stepped cavity, producing different thicknesses of LCD for the different wavelengths that pass through it, allows a linear correspondence between the wavelengths passing through the LCD to produce true black, high contrast and CRT-like color rendition. A dichroic mirror arrangement is used to overlap differently colored pixels in the projected image.

5900982, May 4, 1999

Nov 3, 1997

8/963016

Eugene Dolgoff - Westbury NY
Malcolm MacFarlane - Brookfield CT
Paul B. Christie - New York NY

Projectavision, Inc. - Jersey City NJ

G02B 2710

359619

A light valve such as an active matrix LCD between crossed polarizers, utilizing, for instance, individual transistors to control each "pixel area" of the LCD and storage elements to store video signal data for each pixel, with optically shielded "dead spaces" between pixels to eliminate electric field cross-talk and non-information-bearing light bleed-through, is illuminated with a bright independent light source which creates a video image projected via specialized projection optics onto an internal or external screen without distortions, regardless of the angle of projection onto the screen. Use of heat sinks, IR reflective coatings, heat absorbing optics, optional fluid and a thermistor controlled pixel transistor bias voltage injection servo circuit stabilizes image performance, maintaining accurate color and contrast levels as the LCD changes temperature. In one embodiment of the invention, use of a multi-color LCD with a stepped cavity, producing different thicknesses of LCD for the different wavelengths that pass through it, allows a linear correspondence between the wavelengths passing through the LCD to produce true black, high contrast and CRT-like color rendition. A dichroic mirror arrangement is used to overlap differently colored pixels in the projected image.
