Randy Robert Hayward, Age 676 Barn Owl Ln, Pittsboro, NC 27312

2012025, Oct 4, 2012

Apr 4, 2011

13/079543

Ramkumar SELVARAJPANDIAN - Tamil Nadu, IN
Randy R. HAYWARD - Pittsboro NC, US
Derek P. FURR - West End NC, US

F16J 15/52
B23P 6/02
E02F 3/04

414680, 74612, 294011

A debris kit for a hydraulic cylinder is disclosed. The debris kit may have a base plate assembly with a slot in a length direction that is configured to accommodate sliding of the hydraulic cylinder, and an attachment feature located around at least a portion of a periphery of the slot. The debris kit may also have a flexible boot with a first end connectable to the hydraulic cylinder, and a second end connected to the attachment feature of the base plate assembly.

5803863, Sep 8, 1998

Mar 3, 1997

8/813958

Randy R. Hayward - Mapleton IL
James E. Winzeler - East Peoria IL

Caterpillar Inc. - Peoria IL

F16H 5972

477 98

A transmission warm-up control strategy is provided for an automatic transmission used in a machine that is started or operated in cold conditions. When the operating value of the oil in the transmission is below a predetermined level, as sensed by a temperature sensor or a viscosity sensor, a controller turns on an indicator lamp, de-energizes all of the solenoid to the solenoid actuated valves, and holds for a predetermined period of time. The respective solenoids are incrementally energized and held for a second period of time while continuously monitoring the operating condition of the oil in the transmission. Once the operating condition of the oil is above the predetermined operating value, the indicator lamp is turned off and the system is returned to normal operating conditions. If the shift lever is moved from the park position during warm-up, all solenoids are de-energized and the indicator lamp is set to flash. The condition is held for the first predetermined period of time then the solenoids for the neutral clutches are energized and if the shift lever is not in the neutral position, the controller require that the shift lever be returned to the neutral or park position.

5784917, Jul 28, 1998

Mar 3, 1997

8/813960

Randy R. Hayward - Mapleton IL

Caterpillar Inc. - Peoria IL

F16H 5972

74335

A shift control strategy is provided for an automatic transmission used in a machine that is started or operated with cold oil in the transmission. When the operating value of the oil in the transmission is below a predetermined level, as sensed by a temperature sensor or a viscosity sensor, a controller turns on an indicator lamp. When a shift lever is moved from the neutral position or moved to select a different direction of travel, the controller detects the amount of time the shift lever has been in the neutral position or out of the one direction of travel and compares the amount of time to a predetermined amount of time. If the amount of time is less than the predetermined amount of time, the controller flashes the indicator lamp, inhibits the engagement of the clutches for the desired gear ratio or new travel direction, and requires the shift lever be moved back to the neutral position.

6173228, Jan 9, 2001

Jul 31, 1998

9/127487

Robert D. Carlson - Plainfield IL
Randy R. Hayward - Mapleton IL
Laurence M. Rubin - Raleigh NC
Steven T. Ufheil - East Peoria IL

Caterpillar Inc. - Peoria IL

B60K 4124

701 51

A method and apparatus for controllably engaging, or disengaging, or both engaging and disengaging, a neutralize mode associated with a transmission located on a machine is disclosed. The machine has a controller, a memory associated with the controller, and a braking system. A determined system brake pressure is compared with at least one of an established neutralize pressure value and in gear pressure value. The neutralize mode is engaged or disengaged in response to the comparison.

5848952, Dec 15, 1998

Mar 3, 1997

8/811091

Randy R. Hayward - Mapleton IL

Caterpillar Inc. - Peoria IL

B60K 4128
B60K 4118

477116

A gear dependent manual modulation transmission control strategy is provided in a machine having an inching control arrangement so that during inching control operation the pressure of the fluid being directed to the selected clutches verses the displacement of the inching pedal can be changed relative to the selected gear ratio. This is accomplished by disposing a solenoid actuated manual modulation valve between a source of pressurized fluid and certain ones of the fluid actuated clutches and a controller operating to change the pressure relationship by changing the magnitude of the signal to the solenoid actuated manual modulation valve upon receiving a signal from a shift lever indicating a different pre-selected gear ratio.
