Richard J Markel, Age 681312 E Washington St, Greenville, SC 29607

4288407, Sep 8, 1981

Jun 8, 1978

5/913758

Richard F. Markel - Greenville SC
W. M. Goldberger - Columbus OH

B01J 842

422143

A method and apparatus for the continuous high temperature treatment of sulfur-containing carbonaceous particles in an electrothermally heated fluidized bed is disclosed. In one aspect of the invention, a fluidizing stream is passed through carbonaceous particles introduced into a fluidizing zone at a velocity sufficient to fluidize said carbonaceous particles. The carbonaceous particles are heated in a fluidized state, and controllably fed into and discharged from the fluidizing zone at a rate sufficient to assure that the sulfur content of the particles are reduced below 0. 5%. In another aspect of the invention, at least a portion of the carbonaceous material is transformed from a relatively amorphous molecular state, into a graphite crystalline state.

4020273, Apr 26, 1977

Nov 26, 1975

5/635515

Robert Dix - Wayne NJ
Richard F. Markel - Greenville SC
James A. Parker - Charlotte NC
John P. Riggs - New Providence NJ
Dale T. Vest - Summit NJ

Celanese Corporation - New York NY

H05B 300

13 7

A vertical pyrolysis furnace used in the carbonization or high temperature heat treatment of a continuous length of organic fibrous material is disclosed. The oven includes a central conduit or passage having a plurality of independently controlled heating zones disposed circumferentially therearound and spaced axially therealong. The conduit and heating elements are surrounded by suitable insulating material and a gas-tight shell. At the top of the furnace an exhaust manifold is provided which communicates with the central conduit. An environmental seal is provided at the upper end of the exhaust manifold and at the bottom of the conduit. Suitable gaseous inlets communicate with the furnace for an inert gaseous atmosphere which is controlled such that free convection causes the gaseous atmosphere to rise vertically through the central conduit to the exhaust chamber located at the upper end thereof. A continuous length of organic fibrous material moves vertically downwardly through the central conduit from the upper environmental seal to the lower environmental seal. The independently controlled heating zones provide a vertically downwardly increasing temperature gradient, up to a desired maximum value which extends over a prescribed length, which drives off toxic gaseous by-products from the continuous length of organic fibrous material.

4160813, Jul 10, 1979

Jul 21, 1978

5/926901

Richard F. Markel - Greenville SC
W. M. Goldberger - Columbus OH

Graphite Synthesis Company - Chicago IL

C01B 3102
C01B 3104

423448

A method and apparatus for the continuous high temperature treatment of sulfur-containing carbonaceous particles in an electrothermally heated fluidized bed is disclosed. In one aspect of the invention, a fluidizing stream is passed through carbonaceous particles introduced into a fluidizing zone at a velocity sufficient to fluidize said carbonaceous particles. The carbonaceous particles are heated in a fluidized state, and controllably fed into and discharged from the fluidizing zone at a rate sufficient to assure that the sulfur content of the particles are reduced below 0. 5%. In another aspect of the invention, at least a portion of the carbonaceous material is transformed from a relatively amorphous molecular state, into a graphite crystalline state.
