Russell Dean Hughes Deceased3520 Paisley Ct, Ann Arbor, MI 48105

7091442, Aug 15, 2006

Jul 30, 2004

10/909163

Russell Vernon Hughes - Plymouth MI, US

International Aluminium Holdings Limited - Coventry

B23K 10/00

21912145, 21912146, 219137 R

A welding apparatus spot welds an upper sheet and a lower sheet together. A substantially semi-circular hole or notch is formed at an edge of the upper sheet at the desired location of spot welding. When the semi-circular hole or notch is formed, the process does not wrinkle or deform the upper sheet. A clamping cup of the welding apparatus surrounds the semi-circular hole or notch and contacts the upper surface of the upper sheet. A plasma arc torch heats the sheets, allowing entrapped vapors in a coating on the lower sheet to vent freely to the atmosphere. Filler wire is added and melted to fill the semi-circular hole or notch and to secure the overlapping sheets together.

2010025, Oct 14, 2010

Apr 8, 2010

12/756540

Russell Vernon Hughes - Plymouth MI, US

B23K 9/16
B23K 10/00

219 75, 2191215

A welding system includes a gas tungsten arc welding power source having a welding arc contactor, a plasma welding torch, and a gas console that supplies gases to the plasma welding torch. The welding system also includes a coolant flow switch connected in series with the welding arc contactor. Power is not provided from the gas tungsten arc welding power source to the plasma welding torch when the coolant flow switch is not actuated.

2020036, Nov 19, 2020

May 13, 2020

15/930603

Russell V. HUGHES - PLYMOUTH MI, US
Joseph PAVILANIS - ROMULUS MI, US

B22F 3/105
B33Y 30/00
B33Y 40/00

A gas delivery and purging device for an additive manufacturing chamber includes at least one flexible gas tube having a gas inlet, a purging gas outlet, and a sidewall which defines a shape of the tube, and a source of purging gas operatively connected to the at least one flexible purging gas tube for selectively delivering the purging gas to the at least one flexible purging gas tube. The gas outlet includes pores defined in substantially an entire surface area of the sidewall such that the purging gas passes through the pores and is thereby released into the chamber and is suitable for delivering a large volume of purging gas in a laminar flow.

2018005, Feb 22, 2018

Aug 17, 2017

15/679466

- Westland MI, US
Russell Vernon Hughes - Plymouth MI, US

B23K 9/12
B23K 10/02
B23K 9/09
B33Y 30/00

A plasma arc welding system includes at least two wire delivery mechanisms and at least two wires. Each of the two wires is delivered by one of the at least two wire delivery mechanisms.

2016022, Aug 4, 2016

Apr 8, 2016

15/093820

- Westland MI, US
Russell Vernon Hughes - Plymouth MI, US

B23K 35/02

An electrode includes an elongated body defining a longitudinal axis. A seating end portion includes a first truncated cone. The first truncated cone has a first truncated end and an opposing conical end. A working end portion includes a second truncated cone having a second truncated end. A constant length is defined between the opposing conical end and the second truncated end. The constant length is about 0.875 inch +/−0.001 inch. The elongated body is located between the seating end portion and the working end portion.

2016022, Aug 4, 2016

Apr 8, 2016

15/093831

- Westland MI, US
Russell Vernon Hughes - Plymouth MI, US

B23K 35/02
B23K 9/28

A welding torch assembly includes a mounting plate. A welding torch is mounted to the mounting plate. The welding torch includes an adjustment track fixed to the mounting plate, an adjustment body slidable relative to the adjustment track, a torch body, an electrode holder having a longitudinal axis. An electrode includes an elongated body defining a longitudinal axis. A seating end portion includes a first truncated cone. A working end portion includes a second truncated cone. The elongated body is located between the seating portion and the working portion. A retaining nut secures the electrode in the electrode holder. The electrode retaining nut contacts the angled surface of the seating end portion. A shield gas cup is secured to the torch body that forms a welding arc to melt filler wire.

2016012, May 12, 2016

Dec 29, 2015

14/982010

- Westland MI, US
Russell Vernon Hughes - Plymouth MI, US

B23K 35/02
B23P 19/04

An electrode includes a working end portion defining a first truncated cone. A seating end portion defines a second truncated cone and including a threaded portion having a plurality of threads with a thread angle of 55. An elongated body defines a longitudinal axis. The elongated body is located between the seating end portion and the working end portion. A method is also disclosed.

2016010, Apr 21, 2016

Dec 29, 2015

14/982014

- Westland MI, US
Russell Vernon Hughes - Plymouth MI, US

B23K 9/32

A nozzle for a welding torch includes a body portion defining an internal bore, a discharge orifice, and an internal radius on the internal bore proximate to the discharge opening.
