Thomas E GaudetteSan Francisco, CA

7145414, Dec 5, 2006

Jun 30, 2004

10/883401

Douglas Seiji Okamoto - South San Francisco CA, US
Anthony C. Sweeney - Salem NH, US
Thomas M. Gaudette - Boston MA, US

Endwave Corporation - San Jose CA

H03H 7/38

333 34, 333246

A circuit structure may include first and second transmission lines, each with a center conductor extending along or between one or more spaced-apart conducting surfaces. A conducting surface, such as a ground, reference, or signal-return plane, of the first transmission line may have an orientation that is transverse to the orientation of a conducting surface of the second transmission line. Each of the conducting surfaces of the first transmission line may contact one or more of the conducting surfaces of the second transmission line. In some examples, one or both of the transmission lines are slablines, and in some examples, the contacting edges or edges adjacent the contacting edges of the respective conductive surfaces are curved.

7165253, Jan 16, 2007

Jan 20, 2004

10/761888

Melissa J. Pike - Milford MA, US
Patrick L. Edson - Newton MA, US
Li Yang - Franklin MA, US
Christian Portal - Holliston MA, US
Thomas Gaudette - Jamaica Plain MA, US

The MathWorks, Inc. - Natick MA

G06F 9/46

718102, 707101, 707102, 717114

A cross-platform interface tool provides a common interface for any hardware or software component having some advertising mechanism listing its features, input, and output requirements. The advertising mechanism can take a number of different forms, including data, a software object definition, or a communications system. The cross-platform interface tool includes a parsing mechanism for parsing through a component description associated with at least one of the plurality of components to gather information relating to the components. A component interface creator automatically generates a component interface based on the information gathered by the parsing mechanism.

7454659, Nov 18, 2008

Dec 30, 2004

11/028171

Thomas Gaudette - Jamaica Plain MA, US
Loren Dean - Natick MA, US
Greg Taillefer - Wrentham MA, US

The MathWorks, Inc. - Natick MA

G06F 11/00

714 33

A method, system and computer program product is disclosed for conducting a test in a distributed fashion in a test environment. A host or client may define a test for testing units under test to evaluate the parameters and characteristics of the units under test. The host or client can distribute at least a portion of the test to a remote instrument that includes a worker. The worker enables the instrument to perform at least portion of the test defined in the host or client. The instrument conduct the at least a portion of the test and may provide the results of the at least a portion of the test for the host or client. As such, the present invention allows the use of multiple resources on a network to conduct the test in a distributed fashion.

7502031, Mar 10, 2009

Dec 20, 2006

11/642431

Melissa J. Pike - Milford MA, US
Patrick L. Edson - Newton MA, US
Li Yang - Franklin MA, US
Christian Portal - Holliston MA, US
Thomas Gaudette - Jamaica Plain MA, US

The MathWorks, Inc. - Natick MA

G06T 15/00

345589, 715716, 715717, 712 32, 718102

A cross-platform interface tool provides a common interface for any hardware or software component having some advertising mechanism listing its features, input, and output requirements. The advertising mechanism can take a number of different forms, including data, a software object definition, or a communications system. The cross-platform interface tool includes a parsing mechanism for parsing through a component description associated with at least one of the plurality of components to gather information relating to the components. A component interface creator automatically generates a component interface based on the information gathered by the parsing mechanism.

7908313, Mar 15, 2011

Dec 12, 2005

11/301061

Roy Lurie - Hopkinton MA, US
Thomas Gaudette - Jamaica Plain MA, US

The MathWorks, Inc. - Natick MA

G06F 15/16

709203, 709202, 710303

An instrument-based distributed computing system is disclosed that accelerates the measurement, analysis, verification and validation of data in a distributed computing environment. A large computing work can be performed in a distributed fashion using the instrument-based distributed system. The instrument-based distributed system may include a client that creates a job. The job may include one or more tasks. The client may distribute a portion of the job to one or more remote workers on a network. The client may reside in an instrument. One or more workers may also reside in instruments. The workers execute the received portion of the job and may return execution results to the client. As such, the present invention allows the use of instrument-based distributed system on a network to conduct the job and facilitate decreasing the time for executing the job.

7958454, Jun 7, 2011

Apr 19, 2005

11/110182

Thomas Gaudette - Jamaica Plain MA, US

The MathWorks, Inc. - Natick MA

G06F 3/00
G06F 3/048

715763, 715762

Systems and methods are provided for the design, development and execution of a graphical user interface using a state machine based programming paradigm integrated with a componentized graphical user interface. The present invention generates a graphical state machine representation of the graphical user interface including states for elements of the graphical user interface and any events associated with these elements. The state diagram model provides a graphical structure for handling events associated with the graphical user interface, such as events generated by inputs provided by a user via a graphical user interface element. Furthermore, functionality for the graphical user interface, such as underlying control structure, state management, and event processing can be implemented with a high level textual programming language integrated with the graphical state machine.

7970594, Jun 28, 2011

Jun 30, 2005

11/173977

Thomas Gaudette - Jamaica Plain MA, US

The MathWorks, Inc. - Natick MA

G06F 17/50
G06F 11/00

703 13, 703 14, 703 20, 714 44, 714715, 714735, 714736, 714742, 716 4, 716 5

A mechanism for exploiting the data gathered about a system model during the system design phase to aid the identification of errors subsequently detected in a deployed system based on the system model is disclosed. The present invention utilizes the coverage analysis from the design phase that is originally created to determine whether the system model as designed meets the specified system requirements. Included in the coverage analysis report is the analysis of which sets of test vectors utilized in simulating the system model excited individual components and sections of the system model. The present invention uses the information associated with the test vectors to select appropriate test vectors to use to perform directed testing of the deployed system so as to confirm a suspected fault.

8090565, Jan 3, 2012

Jan 8, 2008

11/970897

Thomas Gaudette - Jamaica Plain MA, US

The MathWorks, Inc. - Natick MA

G06F 11/277

703 13, 703 6, 703 14, 703 16, 703 17, 703 20, 703 21, 714100, 714 2, 714 3, 714 32, 714 44, 714 46, 714715, 714735, 714736, 714737, 714738, 714742, 716100, 716105, 716106, 716107, 716111, 716136

In one embodiment, a system model models characteristics of a real-world system. The system model includes a plurality of sub-portions that each correspond to a component of the real-world system. A plurality of test vectors are applied to the system model and coverage achieved by the test vectors on the sub-portions of the system model is measured. In response to a failure of the real world system, a suspected failed component of the real-world system is matched to a particular sub-portion of the system model. A test vector to be applied to the real-world system to test the suspected failed component is selected in response to coverage achieved on the particular sub-portion of the system model.
