John E Millward, Age 57108 200, Littleton, UT 84050

6739747, May 25, 2004

Feb 22, 2002

10/081443

John P. Millward - North Ogden UT, 84414

B01F 312

3661671, 3681741, 368184

A dry supplement injection system produces a supplement slurry which is continuously introduced into a flow of irrigation water. The injection system includes a hopper having a cylindrical upper portion and a tapered lower portion terminating at a slurry outlet opening. An inverted perforated funnel assembly is disposed within the hopper. A spray nozzle connected to a water inlet pipe sprays water onto the inner surface of the funnel such that particles of micronized supplement in the hopper are washed through the perforated funnel forming a slurry. A mixing pan disposed below the hopper acts as a reservoir to hold slurry until pumped out through a slurry pump which pumps the slurry into a pressurized irrigation water pipe. Gravity feed of the slurry may replace the slurry pump for applications where the irrigation water is non-pressurized such as flood irrigation.
