Peng M Shao, Age 41St Paul, TX

2021038, Dec 16, 2021

Aug 27, 2021

17/459481

- San Jose CA, US
Peng SHAO - San Jose CA, US

Firefly Dimension, Inc. - San Jose CA

G06F 3/01
G06T 7/73
G06F 3/041
G01S 5/22
G06F 3/0481

A system for human interaction with virtual objects comprises: a touch sensitive surface, configured to detect a position of a contact made on the touch sensitive surface; a reference layer rigidly attached to the touch sensitive surface and comprising one or more patterns; a display device, configured to display a virtual object that is registered in a reference coordinate fixed with respect to the touch sensitive surface; one or more image sensors rigidly attached to the display device, configured to capture an image of at least a portion of the one or more patterns; and at least one processor, configured to determine a position and an orientation of the display device with respect to the touch sensitive surface based on the captured image, and identify an interaction with the virtual object based on the detected position of the contact made on the touch sensitive surface.

2020040, Dec 24, 2020

Jun 19, 2020

16/907070

- San Jose CA, US
Peng SHAO - San Jose CA, US

G02B 27/01

An augmented reality device includes two optical combiners configured to correspond to two eyes of a user respectively, each of the two optical combiners comprising an internal surface for reflecting light from the image source to a respective eye of the user, wherein the internal surface is a freeform surface with a surface function that is based on an XY-polynomial including at least one multivariate monomial; an image source positioned above the eyes of the user to emit light onto the optical combiners, wherein the image source comprises two active displaying areas which are on two different planes; and a housing structure configured to maintain relative position and orientation of the optical combiners and the image source.

2020004, Feb 6, 2020

Aug 2, 2019

16/530823

- San Jose CA, US
Peng Shao - San Jose CA, US

G06F 3/01
G06T 7/73
G06F 3/041
G06F 3/0481
G01S 5/22

A system for human interaction with virtual objects comprises: a touch sensitive surface, configured to detect a position of a contact made on the touch sensitive surface; a reference layer rigidly attached to the touch sensitive surface and comprising one or more patterns; a display device, configured to display a virtual object that is registered in a reference coordinate fixed with respect to the touch sensitive surface; one or more image sensors rigidly attached to the display device, configured to capture an image of at least a portion of the one or more patterns; and at least one processor, configured to determine a position and an orientation of the display device with respect to the touch sensitive surface based on the captured image, and identify an interaction with the virtual object based on the detected position of the contact made on the touch sensitive surface.

2016012, May 5, 2016

Oct 31, 2014

14/530660

Hai Yong Zhang - San Jose CA, US
Wenfeng Zhang - San Jose CA, US
Chenchen Zheng - San Jose CA, US
Peng Shao - San Jose CA, US
Jia Chi Wu - San Jose CA, US
Jia Ning Zhao - Fremont CA, US
David Pommerenke - Rolla MO, US

G02B 27/01

A device comprising means for engaging said device to at least a portion of an outside surface of a glass of a headwear, means for engaging said device to at least a portion of an inside surface of glass of said headwear, means for mounting a display module or video capturing device and said means for engaging said device to at least a portion of an inside surface of a headwear to said device, and means for adjusting a viewing angle of said display module or video capturing device with a generally 360 degrees rotation.
