Timothy J Mattson, Age 7020168 Millrun Dr, Estero, FL 33928

5011465, Apr 30, 1991

Apr 20, 1990

7/511697

Dennis L. Jeffries - Waterloo IA
Gordon L. Marquart - Jesup IA
Timothy J. Mattson - Golden Valley MN

Deere & Company - Moline IL

F16H 5710

475279

An in-line transmission provides 26 useful speeds, including 19 forward speeds and 7 reverse speeds. The transmission includes a main planetary having three sets of planetary gears, as well as a separate hi-lo planetary. At least the first and second sets of planetary gears on the main planetary carrier are formed of double gears. Each side of the first set of double gears has its own ring gear which is independently brakable relative to the housing and its own sun gear. Drive from the input shaft to these two sun gears is provided along two main paths, one direct and the other through the hi-lo planetary. One side of the second set of double gears also has an independently brakable ring gear, as well as a sun gear connected to the output shaft. However, the other side of the second set of double gears meshes only with the third set of planetary gears, which preferably are single gears. The third set of planetary gears has its own independently brakable ring gear, and its own sun gear which is both brakable to the housing and clutchable to the main planetary carrier.

4650048, Mar 17, 1987

Sep 24, 1985

6/779555

Stanley M. Gregerson - Cedar Falls IA
Robert E. Haight - Waterloo IA
Timothy J. Mattson - Austin TX

Deere & Company - Moline IL

B60K 4122

192 357

A control system for preventing engagement of a transmisson when its power source is started with the transmission in gear. The system uses a control valve, an engagement override valve, a check valve and a relief valve to interrupt fluid flow to clutch or brake elements during initial startup unless the transmission is in neutral or park. Unwanted triggering of the override system upon a reduction of hydraulic pressure is avoided in this control system. The control valve of this system may be made responsive to clutch pedal or shift lever movement.

4225151, Sep 30, 1980

Jul 17, 1978

5/925335

Mark A. Taute - Waterloo IA
Richard Treichel - Cedar Falls IA
Jeffrey C. Marks - Waterloo IA
Timothy J. Mattson - Waterloo IA

Deere & Company - Moline IL

B62D 1700

280661

An agricultural tractor with over-size front tires for use with a mechanical front wheel drive is provided with large caster angle front wheels to allow a front wheel to tuck under the tractor to achieve small radius turns.

4177723, Dec 11, 1979

Feb 8, 1978

5/876055

Wesley F. Buchele - Ames IA
Dennis L. Jeffries - Waterloo IA
Ricky D. Madson - Ames IA
Timothy J. Mattson - Waterloo IA
Gregory E. Sparks - Waterloo IA
Raymond D. Thompson - Waterloo IA
Howard T. Uehle - Waterloo IA

Iowa State University Research Foundation, Inc. - Ames IA

B65B 1320
B30B 930

100 8

A compactor device for large round bales is disclosed comprising a horizontally disposed cylindrical housing containing a plunger, a double toggle mechanism connected to the plunger, a hydraulic cylinder connected to the double toggle mechanism for driving the plunger, and a stabilizer linkage connected to the plunger and the double toggle mechanism for maintaining the plunger in a vertical position during compaction of a bale.
